A&D UA-660 - Symbols

E-6
Symbols
Symbols that appear on the display
Symbols Function/Meaning Recommended Action
Appears while measurement is in
progress. It blinks when the pulse
is detected.
Measurement is in progress.
Remain as still as possible.
Irregular Heartbeat symbol
(I.H.B.) Appears when an irregular
heartbeat is detected. It may light
when a very slight vibration like
shivering or shaking is detected.
––––––––––––
Previous mesurememts stored in
memory.
FULL BATTERY – The battery
power indicator during measurement.
––––––––––––
LOW BATTERY
The battery is low when it blinks.
Replace all batteries with new
ones, when the indicator blinks.
Unstable blood pressure
due to movement during the
measurement.
Take another measurement.
Remain still during the
measurement.
The systolic and diastolic values
are within 10 mmHg of each other.
Apply the cu󰀨 correctly, and
try the measurement again.
The pressure value did not
increase during ination.
The cu󰀨 is not applied correctly.
Pulse display error. The pulse is
not detected correctly.
Monitor internal error
Press the START/STOP
button. If the error still
appears, contact the dealer.
AM Time in the morning ––––––––––––
PM Time in the afternoon ––––––––––––
