E-7
Symbols
Symbols that appear on the display
Symbols Function/Meaning Recommended Action
Appears while measurement
is in progress. It blinks when
the pulse is detected.
Measurement is in progress.
Remain as still as possible.
Irregular Heartbeat symbol
(I.H.B.) appears when
an irregular heartbeat is
detected.
It may light when a very slight
vibration like shivering or
shaking is detected.
––––––––––––––––
Appears when a body or arm
movement is detected.
The reading may yield an
incorrect value. Take another
measurement. Remain still
during measurement.
Appears during measurement
when the cu is attached
loosely.
The reading may yield an
incorrect value. Apply the cu
correctly, and take another
measurement.
User
––––––––––––––––
Previous measurements
stored in memory.
––––––––––––––––
Average data
––––––––––––––––
FULL BATTERY
The battery power indicator
during measurement.
––––––––––––––––
LOW BATTERY
The battery is low when it
blinks.
Replace all batteries with new
ones when the indicator blinks.
