AAON CL SERIES User Manual

CL Series Feature String Nomenclature
Model Options
Feature Options
GEN
SIZE
VLT
INT PRT
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
CL
-
125
-
3
-
0
-
B
E
0
4
-
0
0
0
:
0
0
0
0
-
0
0
0
-
0
0
0
-
0
0
0
-
J
A
F
0
0
B
H
-
0
0
-
0
0
0
A
0
0
B
0
B
15
16
17
18
19
20
21
22
23
12
5A: Blank
0 = Standard
5B: Blank
0 = Standard
5C: Blank
0 = Standard
6A: Blank
0 = Standard
6B: Blank
0 = Standard
6C: Blank
0 = Standard
7: Refrigeration Control
0 = Standard
A = 5 Min Time Delay Relay Off
B = 20 Sec Time Delay Relay
C = 115V Outlet, Field Wired
D = 115V Outlet, Factory Wired
E = Options A + B
F = Options A + C
G = Options A + D
H = Options A + B + C
J = Options A + B + D
K = Options B + C
L = Options B + D
8: Refrigeration Options
0 = Standard
A = Hot Gas Bypass on Lead Stage
D = Hot Gas Bypass on Lead and Lag Stages
9: Refrigeration Accessories
0 = Standard
A = Sight Glass
B = Compressor Isolation Valves
C = Sight Glass + Compressor Isolation Valves
F = Compressor Isolation Valves + Condenser Fan
VFDs
G = Compressor Isolation Valves + Condenser Fan
VFDs + Sight Glass
10: Power Options
0 = Standard Single Point Power Block
A = Single Point Power Non-Fused Disconnect
(250A)
B = Single Point Power Non-Fused Disconnect
(400A)
C = Single Point Power Non-Fused Disconnect
(600A)
D = Single Point Power Non-Fused Disconnect
(800A)
E = Single Point Power Non-Fused Disconnect
(1200A)
11: Blank
0 = Standard
12: Controls
0 = Standard
B = Phase & Brown Out Protection
13: Special Controls
0 = Standard
D = VAV Unit Controller
E = Constant Volume Unit Controller
F = Make up Air Unit Controller
H = Field Installed DDC Controls by Others
J = Factory Installed DDC Controls by Others

AAON CL SERIES Specifications

General

Brand	AAON
Model	CL SERIES
Category	Heat Pump
Language	English
