AAON CL SERIES User Manual

CL Series Feature String Nomenclature
Model Options
Feature Options
GEN
SIZE
VLT
INT PRT
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
CL
-
125
-
3
-
0
-
B
E
0
4
-
0
0
0
:
0
0
0
0
-
0
0
0
-
0
0
0
-
0
0
0
-
J
A
F
0
0
B
H
-
0
0
-
0
0
0
A
0
0
B
0
B
15
16
17
18
19
20
21
22
23
11
CL Series Feature String Nomenclature
MODEL OPTIONS
Series and Generation
CL
Unit Size
045 = 45 Nominal Tons
060 = 60 Nominal Tons
070 = 70 Nominal Tons
075 = 75 Nominal Tons
095 = 95 Nominal Tons
100 = 100 Nominal Tons
110 = 110 Nominal Tons
125 = 125 Nominal Tons
134 = 134 Nominal Tons
135 = 135 Nominal Tons
155 = 155 Nominal Tons
170 = 170 Nominal Tons
190 = 190 Nominal Tons
210 = 210 Nominal Tons
230 = 230 Nominal Tons
Voltage
2 = 230V/3Φ/60Hz
3 = 460V/3Φ/60Hz
4 = 575V/3Φ/60Hz
8 = 208V/3Φ/60Hz
Interior Corrosion Protection
0 = Standard
A1: Cooling - Compressor Style
B = R-410A Dual Circuited Scroll Compressor
R = R-410A Independently Circuited Compressors
A2: Cooling - Condenser Style
A = Air-Cooled Condenser
E = Evaporative Condenser
A3: Cooling - Coating
0 = Standard
B = Polymer E-Coated (Condenser)
A4: Cooling - Staging
2 = 2 Stage
3 = 3 Stage
4 = 4 Stage
6 = 6 Stage
8 = 8 Stage
B1: Heating - Type
0 = No Heat
B2: Heating - Designation
0 = No Heat
B3: Heating - Staging
0 = No Heat
UNIT FEATURE OPTIONS
1A: Blank
0 = Standard
1B: Blank
0 = Standard
1C: Blank
0 = Standard
1D: Blank
0 = Standard
2: Blank
0 = Standard
3: Blank
0 = Standard
4: Blank
0 = Standard

AAON CL SERIES Specifications

General

Brand	AAON
Model	CL SERIES
Category	Heat Pump
Language	English
