Operating and display elements
18 Aastra 5380/Aastra 5380ip
eud-1282/1.3 – R3.0 – 04.2013
Display symobls
Display symbols on the phone
Status information
Detailed information available Other Foxkeys available (Foxkey)
Search mode Function activated
Entries in call list New text messages
Forwarding activated Call Forwarding on No Reply activated
New voice messages
• Voice message retrieved
• Voice mail greeting with possibility
to leave a voice message
Voice mail greeting without possibility
to leave a voice message
New forwarded voice message
[a]
Retrieved forwarded voice message
[a]
Hi-Q™ during a call (enhanced audio
quality) (only Aastra 5380ip)
Data and voice encryption (only
Aastra 5380ip)
Call parked Retrieve parked call (Foxkey)
Activate discreet ringing Melody deactivated
Microphone deactivated
Loudspeaker/hands-free mode acti-
vated
Headset mode activated Telephone barred
