15
GENERAL OVERVIEW
1.4 MOTOR SIDE
31 LCD Control Panel displays AatonCode, ASA, speed, voltage, remaining footage.
32 Carrying Handle includes tape measure stud, 3/8-16 accessory hole and adjusting tools.
33 Lemo5 AatonCode and SMPTE timecode communication.
34 Lightmeter On/Off activates the lightmeter display in the viewfinder.
35 LED Indicators motor side indicators for camera run, camera test and low battery.
36 Motor triphase salarium, low power consumption. 3-75 fps operation.
37 Aaton Jog provides quick adjustment of Aatonite, ASA, speed, phasing, footage.
38 AatonCode Led flashes each second if the timecode has been initialized in the camera.
39 Feed Latch locks the magazine feed door.
40 Mag Footage Counter displays the footage remaining in the magazine feed side.
31 32
33 34 35 36 37 38 39 40
