Focus Adjusment / Throw Distance
5
DIAGONAL SCREEN SIZE
16:9 Aspect Ratio
Throw Distance
Units: Inches
19
38
58
77
96
115
153
192
Diagonal Size
Units: Inches
20
40
60
80
100
120
160
200
• Spin the focus wheel up or down until the image becomes
clear.
Focus Adjustment
Throw Distance Chart
Throw Ratio 1.10
Projection Angle: 100% Offset
*minimum throw distance: 12 inches
