Focus Adjusment / Throw Distance
6
DIAGONAL SCREEN SIZE
16:9 Aspect Ratio
• Spin the focus wheel up or down until the image becomes
clear.
Focus Adjustment
Throw Distance Chart
Throw Ratio 1.20
Projection Angle: 100% O󰀨set
*minimum throw distance: 10 inches
Throw Distance
Unit: Inches
20
30
40
50
60
70
80
90
Diagonal Size
Unit: Inches
19
29
38
48
57
67
76
86
