Step-by-step drawings for an installation example of standard drive configuration in Rittal VX25 800 mm wide cabinet 13
Combi screw M8
24 N·m
Combi screw M8
24 N·m
M6 Serpress
8 N·m
Screw M10x30
and washer
M6 Serpress
8 N
·m
