ABB ACQ580-34 Quick Installation Guide

20 Step-by-step drawings for an installation example of standard drive configuration in Rittal VX25 800 mm wide cabinet
Tapping screw M6×12
Torx T30 (Hex) 8 N·m
730.5 (28.76)
Rear air baffle, non-ABB part
(see dimension drawings)
Right air baffle, non-ABB part
(see dimension drawings)
Rittal 8617.730
Rittal 8617.730
Rittal 8617.720
Rittal 8617.720
Left air baffle, non-ABB part
(see dimension drawings)
Front air baffle, non-ABB part
(see dimension drawings)

ABB ACQ580-34 Specifications

General

Brand	ABB
Model	ACQ580-34
Category	Control Unit
Language	English
