07 ELECTRICAL INSTALLATION
3BHS213401 E01 REV H ACS1000 AIR-COOLED USER MANUAL 89/184
7.5 Power cables, ground cables and equipotential
bonding conductor
7.5.1 Preparing the cable entry and the cables
NOTICE
7.5.1.1 Maximum number of cables per phase
The maximum number of cables that can be used per phase depends on the type of the drive
and its nominal voltage.
Table 7-1: Maximum number of cables per phase
7.5.1.2 Determining the cable length
1. Determine the required length of a cable between the point of entry and the connection
point inside the cabinet.
2. Cut the cable to the required length before connection.
See layout drawing in “Appendix C – Mechanical drawings” for information on:
- Project-specific cable entry
- Distance between point of cable entry and terminals
- Busbar and fastening hole dimensions
- Busbar designations
See “Appendix D – Wiring diagrams” for information on:
- Conventions for cross-reference and device identification
Risk of damage or malfunction!
- Waste inside the cabinet can cause damage or malfunction.
- If possible, do not cut cables inside the terminal compartment.
- Retrieve any waste which accidentally dropped into the cabinet.
ACS1000 type 2.3 kV nominal voltage 3.3 kV nominal voltage 4.0 kV nominal voltage
A1 1 cable per phase 1 cable per phase 1 cable per phase
A2 2 cables per phase 1 cable per phase 1 cable per phase
A3 2 cables per phase 2 cables per phase 1 cable per phase
