ACS 300 User’s Manual 5
Chapter 1 - Overview of This Manual
Identification Labels
Type Designation
Figure 1-1 Type designation of the ACS 300 frame sizes R0 and R1
(code printed on the nameplate located at the right side of the heatsink).
Figure 1-2 Type designation of the ACS 300 frame size R2.
Internal number
Week
Year
Voltage 3 - 380...480 V
1 - 200...240 V
Power
Wall mounted
0 - internal RFI-filter
1 - without RFI-filter
SERIAL
NUMBER
TYPE
CODE
ABB Industry Oy
Type
ACS30108P73DE
U1 U2
I1n I2n
f1 f2
3~0- 380...480 V3~ 380...480 V
10.6 A 13.2 A
48...63 Hz 0...500 Hz
Serno *
96010001
*
Internal number
Week
Year
0 = Internal
1 = No RFI-filter
3 = 380...480 V and 1 = 200... 240 VPowerWall mounted
RFI-filter
