Control panel overview 19
Status LED
The control panel has a status LED that indicates if there are any faults or warnings
present. The table below shows the meaning of the LED indications.
For further information on fault and warning indications, see Identifying error and
warning messages (page 51).
USB connector
The USB connector is used for connecting the control panel to a PC. When
connected, the control panel acts as an USB adapter for data transfer between the
PC tool and the drive. It is also possible to transfer data between the PC and the
control panel through the USB connection.
RJ-45 connector
The RJ-45 connector is used to electrically connect the control panel to the drive.
Mechanical connection is achieved with the clip on the top.
Type code label
The type code label contains revision information.
Green, continuous The drive is functioning normally.
Green, flickering Data is transferred between the PC tool and drive through the
USB connection of the control panel.
Green, blinking There is an active warning in the drive.
Red, continuous There is an active fault in the drive.
Blue, blinking Bluetooth interface is enabled.It is in discoverable mode and
ready for pairing.
Blue, flickering Data is transfered through the Bluetooth interface of the
control panel.
ABB Oy ACS-AP-W SN:A1250121SB CODE: 3AXD50000025964
3AXD50000025964A1250121SB SW: 5.01 RoHS
FCC ID: 2AFNGAPWSERIES IC: 20555-APWSERIES
Type code
ABB Oy
Bar code
Bar code
in readable
text
FCC ID and IC CANADA numbers
SW version
RoHS marking
MRP code
Serial number
