CHAPTER 3 – CONTROL SYSTEM 50
—
3.2 Main components
This section provides a short functional overview of the main hardware
components of the control system and their interconnection.
—
References
—
3-2 Control compartment
—
3-2
Shown is the ACS2000 for direct-to-line (DTL) connection
Control compartment
Local control panel
1
2
1
2
