59 ACS2000 AFE 2MVA UM 3BHS355653 ZAB E01 REV. H
3.3.2 Standard internal IOEC1 (A3401) module
Analog inputs
3.3.3 Standard external IOEC2 (A3411) module
—
Table 3-4 Standard analog input signal allocation
Terminal Channel Default setting Par. group
X31-1 +10 V
0 V
Internal supply voltage —
X32-1
X31-2 AI1+
AI1-
Freely programmable 72
X32-2
X31-3 AI2+
AI2-
Converter air temperature
X32-3
X31-4 AI3+
AI3-
Freely programmable 72
X32-4
X31-5 AI4+
AI4-
Freely programmable 72
X32-5
—
Table 3-5 Standard digital output signal allocation
Terminal Channel Default setting Par. group
X21-1 DO01 Ready on
(drive is ready for operation)
X21-2
X21-3
X22-1 DO02 Ready ref
(drive is running)
X22-2
X22-3
X23-1 DO03 Alarm / fault
(alarm / fault is present)
X23-2
X23-3
X24-1 DO04 Tripped
(drive has shut down)
X24-2
X24-3
X25-1 DO05 MV switchgear open command
(low active)
X25-2
X25-3
X26-1 DO06 MV switchgear close command
(high active)
X26-2
X26-3
