Digital inputs
—
Table 3-6 Standard digital input signal allocation
Terminal Channel Default setting Par. group
X11-1 DI01 Freely programmable 72
X11-2 Common
X11-3 DI02 Freely programmable 72
X11-4 Common
X11-5 DI03 Freely programmable 72
X11-6 Common
X11-7 DI04 Freely programmable 72
X11-8 Common
X11-9 DI05 Freely programmable 72
X11-10 Common
X12-1 DI06 Freely programmable 72
X12-2 Common
X12-3 DI07 Freely programmable 72
X12-4 Common
X12-5 DI08 Freely programmable 72
X12-6 Common
X12-7 DI09 MV switchgear open *
X12-8 Common
X12-9 DI10 MV switchgear closed *
X12-10 Common
X13-1 DI11 MV switchgear available (not tripped) *
X13-2 Common
X13-3 DI12 Freely programmable 72
X13-4 Common
X13-5 DI13 Freely programmable 72
X13-6 Common
X13-7 DI14 Freely programmable 72
X13-8 Common
X13-9 +24 V
+0 V
24 V control logic —
X13-10 Common
* Not configurable
