CHAPTER 3 – CONTROL SYSTEM 64
Digital inputs
Analog inputs
—
Table 3-11 Optional digital input signal allocation
Terminal Channel Default setting Par. group
X11-1 DI01 Freely programmable
X11-2 Common
X11-3 DI02 Freely programmable
X11-4 Common
X11-5 DI03 Freely programmable
X11-6 Common
X11-7 DI04 Freely programmable
X11-8 Common
X11-9 DI05 Freely programmable
X11-10 Common
X12-1 DI06 Freely programmable
X12-2 Common
X12-3 DI07 Freely programmable
X12-4 Common
X12-5 DI08 Freely programmable
X12-6 Common
X12-7 DI09 Freely programmable
X12-8 Common
X12-9 DI10 Motor protection monitoring
X12-10 Common
X13-1 DI11 Motor vibration 2 / bearing 2 (alarm trip)
X13-2 Common
X13-3 DI12 Motor vibration 1 / bearing 1 (alarm trip)
X13-4 Common
X13-5 DI13 Ext mot trip (ovrtmp / ovrspd / space heater / fan)
X13-6 Common
X13-7 DI14 External motor alarm
X13-8 Common
X13-9 +24 V
+0 V
24 V control logic
X13-10 Common
—
Table 3-12 Optional analog input signal allocation
Terminal Channel Default setting Par. group
X31-1 +10 V
0 V
Internal supply voltage —
X32-1
X31-2 AI1+
AI1-
Motor winding U1 temperature
X32-2
X31-3 AI2+
AI2-
Motor winding V1 temperature
X32-3
X31-4 AI3+
AI3-
Motor winding W1 temperature
X32-4
X31-5 AI4+
AI4-
Freely programmable
X32-5
