ABB ACS2000 DFE - Page 53

CHAPTER 3 – CONTROL SYSTEM 53
X13-3 DI12 Freely programmable 72
X13-4 Common
X13-5 DI13 Freely programmable 72
X13-6 Common
X13-7 DI14 Freely programmable 72
X13-8 Common
X13-9 +24 V
+0 V
24 V control logic —
X13-10 Common
* Not configurable
—
Table 3-6 Standard digital input signal allocation
Terminal Channel Default setting Par. group
—
Table 3-7 Example for digital input signal allocation
Terminal Channel Default setting Par. group
X11-1 DI01 External start / stop request 72.06 – 72.09
X11-2 Common
X11-3 DI02 Forward / reverse 72.10 – 72.11
X11-4 Common
X11-5 DI03 Freely programmable —
X11-6 Common
X11-7 DI04 Ramp 1 / 2 72.41 – 72.42
X11-8 Common
X11-9 DI05 Ext1 / Ext2 30 – 31
X11-10 Common
X12-1 DI06 Constant speed select 24 – 25
X12-2 Common
X12-3 DI07 External ON request (start DC link charge) 72.02 – 72.03
X12-4 Common
X12-5 DI08 Process stop (stops drive) 72.43 – 72.44
X12-6 Common
X12-7 DI09 MV switchgear open *
X12-8 Common
X12-9 DI10 MV switchgear closed *
X12-10 Common
X13-1 DI11 MV switchgear available (not tripped) *
X13-2 Common
X13-3 DI12 Remote reset 72.33 – 72.34
X13-4 Common
X13-5 DI13 External OFF request 72.04 – 72.05
X13-6 Common
X13-7 DI14 Disable local operation 72.35 – 72.36
X13-8 Common
X13-9 +24 V
+0 V
24 V control logic —
X13-10 Common
* Not configurable
