4.1 Safety
The drive must only be handled by personnel who are skilled and
experienced in unpacking and transporting heavy equipment.
—
4.2 Transport conditions
Transformer, Converter and Fans are considered separate
transport sections.
The transport conditions for the drive are based on
IEC 60721-3-2 'Classification of environmental con-
ditions: Classification of groups of environmental
parameters and their severities; Transportation'.
—
Table 4-1 Table 4.1 Transport Conditions
2K12 Climatic conditions
Low air temperature -45 °C
High air temperature
• Unventilated enclosures 70 °C
• Ventilated enclosures / outdoor 40 °C
Relative humidity 100%
Absolute humidity 60%
2B1 Biological conditions
Flora No
Fauna No
2M4 Mechanical conditions
Stationary vibration random
• Acceleration spectral density
10 m
2
/s
3
(2 – 3 Hz)
1 m2/s3 (10 - 20 Hz)
0.5 m
2
/s
3
(50 – 2000 Hz)
Non-stationary vibration (including shock)
• Shock response spectrum
100 m/s
2
, 11 ms duration
300 m/s
2
, 6 ms duration
Free fall 0.1 m
Toppling No
Rolling, pitching
•Angle No
•Period No
Steady-state acceleration
20 m/s
2
