40 Technical data
Rectifier power capacity (P
rec,ave
and P
rec,max
)
U
ac
: AC input voltage.
P
rec,ave
is the average rectifier power capacity of the drive over a 3-minutes time window. The average power
taken from AC power line must be lower than this value during any 3-minutes time window.
1)
Value 630 applies to 600…690 V AC.
P
rec,max
is the maximum rectifier power capacity of the drive allowed for max. 10 s. The instantaneous power
taken from AC power line must never exceed this limit.
R5a: ACS880-01 types -07A3-7, -09A8-7, -14A2-7 and -018A-7.
R5b: ACS880-01 types -022A-7, -026A-7, -035A-7, -042A-7 and -049A-7.
R10a: ACS880-04 types -505A-3 and -460A-5.
R10b: ACS880-04 types -585A-3, -650A-3, -583A-5, -635A-5, -330A-7 and -370A-7.
Frame P
rec,ave
P
rec,max
depending on U
ac
208…240 V AC
(ACS880-01
-xxxx-2)
380…415 V AC
(ACS880-01/-04
-xxxx-3)
380…500 V AC
(ACS880-01/-04
-xxxx-5)
600…690 V AC
(ACS880-01/-04
-xxxx-7)
R1 5.5 7 7 6 -
R2 11 13 13 10 -
R318.526 2624-
R4 30 37 37 32 -
R5a 15 - - - 24
R5b 45 63 63 59 54
R6 75 92 92 79 81
R7 110 153 153 144 150
R8 160 228 228 212 208
R9 250 - 317 262 304
R10a 250 - 340 420 -
R10b 355 - 420 500 510
R11
500/630
1)
- 620 700 850
