ABB ACS880-04 drive modules - Brake chopper ratings and DC voltage limits

44 Technical data
Brake chopper power ratings
P
br,cont
: Continuous braking power of the chopper. The braking is considered continuous if the braking time
exceeds 30 seconds.
R
br,min
: The minimum allowed resistance of the brake resistor used with the brake chopper.
Note: P
br,max
= U
DC,brcl
2
/ R
br, min
: This is the theoretical maximum braking power which
the brake chopper can withstand for a short time. Thermal protection of the brake chopper
can limit the available braking power to a lower value.
Drive type
ACS880-
01-
P
br,
cont
[kW]
R
br,
min
[ohm]
Drive type
ACS880-
01-
P
br,
cont
[kW]
R
br,
min
[ohm]
Drive type
ACS880-
01-
P
br,
cont
[kW]
R
br,
min
[ohm]
Drive type
ACS880-
01-
P
br,
cont
[kW]
R
br,
min
[ohm]
04A6-2 0.75 65 02A4-3 0.75 78 02A1-5 0.75 78 07A3-7 6 18
06A6-2 1.1 65 03A3-3 1.1 78 03A0-5 1.1 78 09A8-7 8 18
07A5-2 1.5 65 04A0-3 1.5 78 03A4-5 1.5 78 14A2-7 11 18
10A6-2 2.2 65 05A6-3 2.2 78 04A8-5 2.2 78 018A-7 17 18
16A8-2 4.0 18 07A2-3 3.0 78 05A2-5 3.0 78 022A-7 23 18
24A3-2 5.5 18 09A4-3 4.0 78 07A6-5 4.0 78 026A-7 28 18
031A-2 7.5 13 12A6-3 5.5 78 11A0-5 5.5 78 035A-7 33 18
046A-2 11 12 017A-3 7.5 39 014A-5 7.5 39 042A-7 45 18
061A-2 11 12 025A-3 11 39 021A-5 11 39 049A-7 45 18
075A-2 18.5 6 032A-3 15 19 027A-5 15 19 061A-7 55 13
087A-2 22 6 038A-3 18.5 19 034A-5 18.5 19 084A-7 65 13
115A-2 30 3.5 045A-3 22 13 040A-5 22 13 098A-7 90 8
145A-2 37 3.5 061A-3 22 13 052A-5 22 13 119A-7 110 8
170A-2 45 2.4 072A-3 37 8 065A-5 37 8 142A-7 132 6
206A-2 55 2.4 087A-3 45 8 077A-5 45 8 174A-7 160 6
274A-2 75 1.8 105A-3 55 5.4 096A-5 55 5.4 210A-7 200 4
145A-3 75 5.4 124A-5 75 5.4 271A-7 250 4
169A-3 90 3.3 156A-5 90 3.3
206A-3 110 3.3 180A-5 110 3.3
246A-3 132 2.3 240A-5 132 2.3
293A-3 132 2.3 260A-5 132 2.3
363A-3 160 2 302A-5 160 2.3
430A-3 160 2 361A-5 160 2.3
414A-5 160 2.3
