ABB ACS880 Series Firmware Manual

—
List of related manuals
You can find manuals and other product documents in PDF format on the Internet. See
section
Document library on the Internet on the inside of the back cover. For manuals not
available in the Document library, contact your local ABB representative.
*Lists of hyperlinks to product manuals Code
ACS880-01 drives 9AKK105408A7004
ACS880-04 drive modules (200 to 710 kW, 300 to 700 hp) 9AKK105713A4819
ACS880-07 drives (45 to 710 kW, 50 to 700 hp) 9AKK105408A8149
ACS880-07 drives (560 to 2800 kW) 9AKK105713A6663
ACS880-07CLC drives hardware manual 9AKK107046A0239
ACS880-07LC drives hardware manual 9AKK107680A9275
ACS880-11 drives 9AKK106930A9565
ACS880-14 drive modules (132 to 400 kW, 200 to 450 hp) 9AKK107045A8023
ACS880-17 drives (45 to 400 kW, 60 to 450 hp) 9AKK106930A3466
ACS880-17 drives (160 to 3200 kW) 9AKK106354A1499
ACS880-17LC drives 9AKK107492A4721
ACS880-31 drives 9AKK106930A9564
ACS880-34 drive modules (132 to 400 kW, 200 to 450 hp) 9AKK107045A8025
ACS880-37 drives (45 to 400 kW, 60 to 450 hp) 9AKK106930A3467
ACS880-37 drives (160 to 3200 kW) 9AKK106354A1500
ACS880-37LC drives 9AKK107492A4722
Other drive hardware manuals
ACS880-04XT drive module packages (500 to 1200 kW)
hardware manual
3AXD50000025169
ACS880-04 single drive module packages hardware
manual
3AUA0000138495
ACS880-14 and -34 single drive packages hardware
manual
3AXD50000022021
ACS880-104 inverter modules hardware manual 3AUA0000104271
ACS880-104LC inverter modules hardware manual 3AXD50000045610
ACS880-107 inverter units hardware manual 3AUA0000102519
ACS880-107LC inverter units hardware manual 3AXD50000196111
Drive firmware manuals and guides
ACS880 primary control program firmware manual 3AUA0000085967
ACS880 drives with primary control program, quick start-
up guide
3AUA0000098062
Adaptive programming application guide 3AXD50000028574
Drive application programming manual (IEC 61131-3) 3AUA0000127808
ACS880 diode supply control program firmware manual 3AUA0000103295
ACS880 IGBT supply control program firmware manual 3AUA0000131562
CIO-01 I/O module user’s manual 3AXD50000126880
Option manuals and guides
ACX-AP-x assistant control panels user’s manual 3AUA0000085685
Drive composer Start-up and maintenance PC tool user’s
manual
3AUA0000094606
Manuals and quick guides for I/O extension modules,
fieldbus adapters, encoder interfaces, etc.

ABB ACS880 Series Specifications

General

Cooling Method	Air-cooled, liquid-cooled
Enclosure class	IP21, IP55
Mounting type	Wall-mounted
Control method	Direct torque control (DTC)
Braking chopper	Integrated or external
Communication	Ethernet
Protection Features	Overcurrent, overvoltage, undervoltage, overload, short circuit, overtemperature, earth fault
Operating Temperature Range	-15°C to +50°C
Storage Temperature Range	-40°C to +70°C
Relative Humidity	5 ... 95 % (non-condensing)
Safety features	Safe torque off (STO)
