354 Parameters
Act1 32bit Actual value ACT1 (32 bits) 15
Act2 32bit Actual value ACT2 (32 bits) 16
SW2 16bit Status Word 2 (16 bits) 24
Other Source selection (see Terms and abbreviations on page 114). -
…… … …
52.12 FBA A data in12 See parameter 52.01 FBA A data in1. None
53
53 FBA A data out
Selection of data to be transferred from fieldbus controller to
drive through fieldbus adapter A.
Note: 32-bit values require two consecutive parameters.
Whenever a 32-bit value is selected in a data parameter, the
next parameter is automatically reserved.
53.01 FBA A data out1 Parameters 53.01…53.12 select data to be transferred from
the fieldbus controller to the drive through fieldbus adapter A.
None
None None. 0
CW 16bit Control Word (16 bits) 1
Ref1 16bit Reference REF1 (16 bits) 2
Ref2 16bit Reference REF2 (16 bits) 3
CW 32bit Control Word (32 bits) 11
Ref1 32bit Reference REF1 (32 bits) 12
Ref2 32bit Reference REF2 (32 bits) 13
CW2 16bit Control Word 2 (16 bits) 21
Other Source selection (see Terms and abbreviations on page 114). -
…… … …
53.12 FBA A data out12 See parameter 53.01 FBA A data out1. None
54
54 FBA B settings
Fieldbus adapter B configuration.
54.01 FBA B type Displays the type of the connected fieldbus adapter module.
0 = Module is not found or is not properly connected, or is
disabled by parameter 50.31 FBA B enable; 1 = FPBA;
32 = FCAN; 37 =FDNA; 101 =FCNA, 128 =FENA-11/21;
135 = FECA; 136 =FEPL; 485 = FSCA.
This parameter is read-only.
-
54.02 FBA B Par2 Parameters 54.02…54.26 are adapter module-specific. For
more information, see the documentation of the fieldbus
adapter module. Note that not all of these parameters are
necessarily in use.
-
0…65535 Fieldbus adapter configuration parameter. 1 = 1
…… … …
54.26 FBA B Par26 See parameter 54.02 FBA B Par2.-
0…65535 Fieldbus adapter configuration parameter. 1 = 1
54.27 FBA B par refresh Validates any changed fieldbus adapter module configuration
settings. After refreshing, the value reverts automatically to
Done.
Note: This parameter cannot be changed while the drive is
running.
Done
Done Refreshing done. 0
No. Name/Value Description Def/FbEq16
