PRODUCT DESCRIPTION
9
Figure 1. Exploded view of the motor.
Item no. Designation
 External shaft seal
 Flange D-end shield
 Nameplate
 Auxiliary connectors
 Power supply connectors
 N-end bearing
 Side mounts
 Shaft splines
 D-end bearing
Table 1. Legend to exploded view, Figure 1.
