MOTORS FOR HEAVY ELECTRICAL VEHICLES
10
2.1. Technical data
The exact type designation and identification data are shown on the rating plate located on the motor,
see Figure 1. An example of a name plate can be seen in Figure 2.
Figure 2. Rating plate example, not to scale.
Position Explanation
Applicable standard
Type of motor
Year of manufacture
Direction of rotation
Connection
Motor weight
N-end bearing
D-end bearing
Maximum rotational speed
Variant codes (options)
Product code
Stall current
1
Rated point
Serial number
Maximum ambient temperature
Type code
Table 2. Explanation of data on rating plate.
1 Only appliable for cUL certifed motors.
