User Interface
C13 20 2CMC486004M0201
User Manual Revision: A
When either Alarm power, Alarm voltage, Alarm current or Alarm factor has
been chosen, the following choices will be available.
Alarm power factor By choosing this option, the
alarm will be set regarding to
the measured power factor.
Pulse output By choosing this option, the
pulse output function will be ac-
tivated.
Out on By choosing this option, the
output will be set to static on.
Out off By choosing this option, the
output will be set to static off.
Exit Go back to the set menu.
Choice Output on display Unit Explanation
Alarm level on W/V/A/- When the measured value
passes the set value, the
alarm will be triggered.
Alarm on delay seconds When the measured value
passes the set value and
remains for the set time,
the alarm will be triggered.
Alarm level off W/V/A/- When the measured value
passes the set value, the
alarm will be cleared.
Alarm off delay seconds
When the measured value
passes the set value and
remains for the set time,
the alarm will be cleared.
Save N/A This option saves the
alarm settings.
Exit N/A Go back to the set menu
without saving. Use this
option to view the current
alarm settings.
Choice in menu Output on display Explanation
