2CMC486001M0201 19 C11
Revision: A User Manual
User Interface
When either Alarm power, Alarm voltage, Alarm current or Alarm factor has
been chosen, the following choices will be available.
Alarm current AL CUr
A
By choosing this option, the
alarm will be set regarding to
the measured current.
Alarm power factor AL PF By choosing this option, the
alarm will be set regarding to
the measured power factor.
Pulse output PUL OUt By choosing this option, the
pulse output function will be ac-
tivated.
Out on OUt On By choosing this option, the
output will be set to static on.
Out off OUt OFF By choosing this option, the
output will be set to static off.
Exit Exit Go back to the set menu.
Choice Output on display Unit Explanation
Alarm level on AL On W/V/A/- When the measured value
passes the set value, the
alarm will be triggered.
Alarm on delay dEL On seconds When the measured value
passes the set value and
remains for the set time,
the alarm will be triggered.
Alarm level off AL OFF W/V/A/- When the measured value
passes the set value, the
alarm will be cleared.
Alarm off delay dEL OFF seconds
When the measured value
passes the set value and
remains for the set time,
the alarm will be cleared.
Save SAuE N/A This option saves the
alarm settings.
Exit EXit N/A Go back to the set menu
without saving. Use this
option to view the current
alarm settings.
Choice in menu Output on display Explanation
