37
t_YES
If YES selected
GO
Repeat for Total 4 (if applicable)
Repeat for Total 3 (if applicable)
t_YES
t_NO
GO
StOP
CH1
CH2
CH3
CH4
AL1 AL2 AL3 AL4
CH1
CH2
CH3
CH4
AL1 AL2 AL3 AL4
CH1
CH2
CH3
CH4
AL1 AL2 AL3 AL4
CH1
CH2
CH3
CH4
AL1 AL2 AL3 AL4
CH1
CH2
CH3
CH4
AL1 AL2 AL3 AL4
CH1
CH2
CH3
CH4
AL1 AL2 AL3 AL4
CH1
CH2
CH3
CH4
AL1 AL2 AL3 AL4
CH1
CH2
CH3
CH4
AL1 AL2 AL3 AL4
CH1
CH2
CH3
CH4
AL1 AL2 AL3 AL4
CH1
CH2
CH3
CH4
AL1 AL2 AL3 AL4
1234
5678
tOtALS
PAGE
rESEt
t2 NO
COUNt
StOP
1234
5678
8765
4321
COUNt
StOP
tOtALS
PAGE
rESEt
t3 NO
8765
4321
8765432112345678
Flow Total 2 and 3Flow Total 2 and 3 Flow Total 3 and 4
6 RECORD OPERATION
6.3 Totals Page Displays
This page is omitted from both faceplates if the Totalizer Option is not fitted. The page is also omitted from faceplate 2 if both Totals
2 and 3 are set to
OFF and from faceplate 3 if both Totals 3 and 4 are set to OFF – refer to the Set Up Totals Page in the Advanced
Software Options Manual
.
Front Panel (Batch) Flow Total 2 (3)
The batch flow total is calculated from process variable
2 (3).
The flashing channel LED indicates the flow total
displayed.
Example – a flashing channel 2 LED indicates Flow Total
2 parameters displayed.
Counter Reset
The Front (Batch) Flow Total can be reset to the
Preset
Value in Set Up Totals Page if Reset Enable in Set Up
Totals Page is set to 'ENbL–Y'.
Select '
t2 YES' to reset the counter ( 't2' indicates
Flow Total 2 ).
Note. If the Counter Reset is disabled in
Set Up Totals
Page, the counter reset frame is omitted.
Counter Stop/Go
Select '
GO' to start the counter or 'StOP' to stop it.
Note. If the Counter Stop/Go is disabled in
Set Up
Totals Page, the frame can be viewed but not altered. If
a digital signal is assigned to the
Totalizer Stop/Go
source, an active digital signal sets the counter to GO
and the Counter cannot be stopped from the front
panel.
Front Panel (Batch) Flow Total 3 (4)
Repeat the above procedure for Flow Total 3 (4).
Note. The number of totalizers is dependent on the
number of pens fitted to the instrument e.g. a 3 pen
instrument has 3 totalizers.
