17
TRANSFORMER COMPONENTS
6.10 Configuration output signal
THIS SETTING IS SIGNIFICANT ONLY FOR
COMEM EDTI MODEL.
THE MAXIMUM LOAD FOR ANALOGUE
NOTE NOTE
In this phase it’s possible to define the type of signal of analogue
output as 0-20 mA or 4-20 mA.
This setting is indicated on displays with:
• AN0 -20 to set the output as 0-20mA or (0 mA = -30°C;
20 mA = 200°C)
• AN4 -20 to set the output as 4-20 mA or (4 mA = -30°C;
20 mA = 200°C)
Confirm with ENTER.
AN
AN
AN
