ABB Comem DTI

26
TEMPERATURE MONITORING DEVICE COMEM DTI AND COMEM EDTI - INSTRUCTION MANUAL
—
Appendix A: MODBUS Address
Register
address
Operations Description Notes
Operation for monitoring
0x280 R CH1 Instantaneous
Temperature [°C]
0x281 R CH2 Instantaneous
Temperature [°C]
0x282 R CH3 Instantaneous
Temperature [°C]
0x283 R CH4 Instantaneous
Temperature [°C]
0x288 R CH1 Maximum
Temperature [°C]
0x289 R CH2 Maximum
Temperature [°C]
0x28A R CH3 Maximum
Temperature [°C]
0x28B R CH4 Maximum
Temperature [°C]
0x290 R CH1 Diagnostic 0x0000 Input is right
connected
0 x 0 0 0 1 I n p u t i s s h o r t e d
0 x 0 0 02 I n p u t i s o p e n
0x0003 Input is failure
0x291 R CH2 Diagnostic
0x292 R CH3 Diagnostic
0x293 R CH4 Diagnostic
0x258 R CH1 Instantaneous
Temperature &
Diagnostic [°C]
0 x 0 0 0 0 I n p u t i s s h o r t e d
0 x 0 0 0 1 I n p u t i s o p e n
0x259 R CH2 Instantaneous
Temperature &
Diagnostic [°C]
0x25A R CH3 Instantaneous
Temperature &
Diagnostic [°C]
0x25B R CH4 Instantaneous
Temperature &
Diagnostic [°C]
Real Value = Read Value (dec) - 25
