8 Configuration level menus
OPrtOr
LEVEL
b A SI C
CONFIG
AdV NCd
CONFIG
Operator level
Basic config
Advanced config
The 2 configuration level menus (Basic and Advanced) are
accessed via the operator level menu.
To access the configuration level menus:
1 From the normal operator view press the key until the
OPrtOr LEVEL page is displayed.
2 Use the and keys to scroll to the required menu.
3 Press the key to scroll through the available settings.
bASIC CONFIG Enables the operator to configure all inputs
and outputs, alarms, security passwords,
pens and chart settings.
AdVNCd CONFIG Enables the operator to configure function
keys, logic equations, pen function and pen
assignment.
