Chapter 5 - Parameter and Signals
5 - 2 DCS 500 12-Pulse Planning and Start-Up
PP_CURR_SLAVE
- Pointer on input of analog value
Master: actual current from Slave
Slave: current reference from Master
3604 P: I2 SC: POINTER HL: 19999 LL: 0 D: 10107 U: -
DIFF_CURR
- Permitted differential in the currents (Master/Slave) in %
- Operative only at the Master drive
3605 P: I2
SC:
%
HL: 50 LL: 1 D: 10 U: -
DIFF_CUR_DEL
- Number of cycles in which the currents are allowed to differ (3605 DIFF_CURR) without
triggering Error 66
- Operative only at the Master drive
3606 P: U2
SC:
NUM
HL: 16383 LL: 3 D: 150 U: -
PP_INH_LOG
- Input to switch-on/switch-off logic with Output Signal 13616
3607 P: I2 SC: POINTER HL: 19999 LL: 0 D: 0 U: -
PP_ISO_LOG
- Input for IREF processing at the Slave
3608 P: I2 SC: POINTER HL: 19999 LL: 0 D: 0 U: -
PP_BRI_LOG
- Input to brdge reversal logic
3609 P: I2 SC: POINTER HL: 19999 LL: 0 D: 0 U: -
PP_REV_LOG
- Input for handling IREF polarity
3610 P: I2 SC: POINTER HL: 19999 LL: 0 D: 0 U: -
PP_X18_09
- The signal passed to this pointer is outputted at Plug Connector X18:09
- Operative in all modes
3611 P: I2 SC: POINTER HL: 19999 LL: 0 D: 0 U: -
PP_X18_10
- The signal passed to this pointer is outputted at Plug Connector X18:10
- Operative in all modes
3612 P: I2 SC: POINTER HL: 19999 LL: 0 D: 0 U: -
