Chapter 6 - Start-Up
DCS 500 12-Pulse Planning and Start-Up 6-3
Parameterizing for
12-pulse mode
Parameter settings for 12-pulse mode
Master
12-pulse
Parameter Name Value Remark
502 I_MOTN_A 50 % of motor rated current
1209 OPER_SYS 1 MASTER operating mode
3611 PP_X18_09 13606 Assignment for X18:9
3612 PP_X18_10 13609 Assignment for X18:10
3608 PP_ISO_LOG 0 Logic for current reference po-
larity
3609 PP_BRI_LOG 13617 Logic for Error 65 - Error at
bridge reversal
3610 PP_REV_LOG 13618 Logic for reversing
Output A02 205 AO2_IND 13605 Current reference after X4:8 to
MASTER
206 AO2_NOMINAL_V ±10000 mV Voltage at X4:8 at 100 %
207 AO2_OFFSET_V 0 mV No offset
208 AO2_NOMINAL_VAL 4095 Calibration, AO2
Input AI2 3604 PP_CURR_SLAVE 10107 Logic for current evaluation -
actual current from Slave to
X3:7
107 AI2_CONV_MODE ±10V /
±20mA
Signal type assignment
108 AI2_HIGH_VALUE 4095 Maximum value of input signal -
pos. values
109 AI2_LOW_VALUE -4095 Maximum value of input signal -
neg. values
Current
monitoring
3605 DIFF_CURR Setting in accordance with op-
erating condition
3606 DIFF_CURR_DEL Setting in accordance with op-
erating condition
Slave
12-pulse
Parameter Name Value Remark
502 I_MOTN_A 50 % of motor rated current
1209 OPER_SYS 2 SLAVE operating mode
3611 PP_X18_09 13611 Assignment for X18:9
3612 PP_X18_10 13609 Assignment for X18:10
3608 PP_ISO_LOG 13617 Logic for current reference po-
larity
3609 PP_BRI_LOG 0 Logic for Error 65 - Error at
bridge reversal
3610 PP_REV_LOG 13618 Logic for reversing
