Chapter 5 - Parameters and Signals
DCS 500 12-Pulse Planning and Start-Up 5 - 3
PP_X18_11
- The signal passed to this pointer is outputted at Plug Connector X18:11
- Operative in all modes
3613 P: I2 SC: POINTER HL: 19999 LL: 0 D: 0 U: -
PP_X18_12
- The signal passed to this pointer is outputted at Plug Connector X18:12
- Operative in all modes
3614 P: I2 SC: POINTER HL: 19999 LL: 0 D: 0 U: -
Group 136: 12-pulse (new)
CONV_CUR_SLA
- Converter current, Slave
- Evaluated signal from Pointer (3604)
- Scaling as with the CONV_CUR_ACT signal (10501)
- Operative only at Master
13601 P:I2 SC: IUnit
read only
ARM_CUR_SLA
- Motor current, Slave
- Evaluated signal from Pointer (3604)
- Scaling as with the CONV_CUR_ACT_A signal (10502)
- Operative only at Master
13602 P:I2 SC: IA1
read only
CONV_CUR_ALL
- Sum of converter currents, Master and Slave
- Evaluated signal from Pointers (3604) and (10501)
- Scaling: half of each current is added together, so that 100 % corresponds to the system’s
total current.
- operative only at Master
13603 P:I2 SC: IUnit
read only
ARM_CUR_ALL
- Sum of motor currents, Master and Slave
- Evaluated signal from Pointers (3604) and (10502)
- Scaling: half of each current is added together, so that 100 % corresponds to the system’s
total current.
- operative only at Master
13604 P:I2 SC: IA1
read only
IREF1
- Current reference before limitation logic
13605 P:I2 SC:TORQUE
read only
