ABB DCS 500 - SIGDCR1_S and SIGDCR1_MA Signals; IREF2 Signal (13608); BRIDGE_S and BRIDGE_SL Signals

Chapter 5 - Parameter and Signals
5 - 4 DCS 500 12-Pulse Planning and Start-Up
SIGDCR1_S
- Polarity of IREF1 for own unit
0 = positive
13606 P:U2 SC:BOOLEAN
read only
SIGDCR1_MA
- Polarity of IREF1 of Master
0 = positive
- Operative only in Slave
13607 P:U2 SC:BOOLEAN
read only
IREF2
- Current reference after limitation logic
13608 P:I2 SC:TORQUE
read only
SIGDCR2_S
- Polarity of IREF2 for own unit
0 = positive
13609 P:U2 SC:
BOOLEAN
read only
SIGDCR2_BR
- Polarity of IREF2 for other unit
0 = positive
13610 P:U2 SC:
BOOLEAN
read only
BRIDGE_S
- Indicate bridge of own unit
0 = Bridge 1 active
13611 P:U2 SC:
BOOLEAN
read only
BRIDGE_SL
- Indicate bridge of Slave
0 = Bridge 1 active
- Operative in Master only
13612 P:U2 SC:
BOOLEAN
read only
REV_INDIC
- Indicate bridge reversal
-1 = Bridge reversal running
13613 P:U2 SC:
BOOLEAN
read only
