7.1.8 Correcting settings
• If after accepting the initial value for the settings you need to correct this value, press the
reset button (3) and repeat the settings.
• If you need to make corrections after saving, the complete setup procedure must be
performed again.
Function Signals
Device setup
Switch to Device Setup: Press and hold both
travel buttons for approx. 5 s.
Both LEDs then flash in sync at 4 Hz.
Reaching an end position: Use the
appropriate button on the ISF.
Both LEDs continue to flash at 4 Hz during
actuator travel.
Save the initial end position: Press 0 % or
100 %.
The corresponding LED flashes at approx.
1 Hz, the others continue to flash at 4 Hz.
Save the second end position: Press 0 % or
100 %.
The related LED flashes at approx. 1 Hz in
sync with the first LED.
Finish Adjustment: Press 0 % and 100 % at
once.
Both LEDs light up briefly and then stop
flashing.
Operation
Standard operation: MAN / AUT The LEDs are switched off.
Positioning via the button on the ISF takes
priority over the control system.
The LEDs are switched off.
Error (both LEDs flash alternately at 4 Hz)
Reset: Resets error messages. If no other error exists, both LEDs stop
flashing.
Reset if the operating range is overshot: Hold
both travel buttons for 5 s and then press the
Reset button.
After approx. 5 s, the flashing is briefly
interrupted. After a reset, the electronic unit
will be in adjustment mode.
Important
After startup, it is recommended that you use the control system to operate the actuator and
check the behavior as well as signaling of the actuator.
To place the actuator in automatic mode after startup, a 24 V DC signal at the digital input 1
must be present for actuators with active digital input functions (default setting).
If the digital function is switched off, the actuator switches to automatic mode immediately after
completing the adjustment process.
