10.1 Power Electronic Unit EBN853 (Contrac)
Pos: 19.3 /Technische D aten / Datenblatt/Akt orik/Antriebe/Lei stungselektronik en/Leistungselek tronik EBN853 (Contrac )/Allgemeine Daten @ 7\mod_116859245285 9_3101.doc @ 58787
Power Electronic Unit EBN853 (Contrac)
Protection Class IP 66
Humidity
≤ 95% average; condensation not permitted
Ambient temperature -25 … 55 °C (-15 … 130 °F)
Mounting position at vertical support, cable gland at the left side
Coating 2-layer component epoxy (RAL 9005, black)
Cable between actuator and
electronic unit
optional 5 m (16 ft), 10 m (32 ft) or 20 m (65 ft) with plug for connection to the actuator; max. cable length
between actuator and electronic unit: 100 m (328 ft).
No plug connection for explosion-proof actuators (RSDE … / RHDE …). Optional, loose cable set supply
acc. to length requirements
Weight; approx. 11 kg (24 lbs)
Pos: 19.4 /Technische D aten / Datenblatt/Akt orik/Antriebe/Lei stungselektronik en/Leistungselek tronik EBN853 (Contrac )/Technische Date n @ 7\mod_1168587809703_31 01.doc @ 58555
Supply voltage (standard actuators) 115 V AC (94 … 130 V) or 230 V AC (190 … 260 V); 47.5 … 63 Hz; 1Ph
Supply voltage (Ex actuators) 115 V AC (94 … 127 V) or 230 V AC (190 … 253 V); 47.5 … 63 Hz; 1Ph
l
max
.
at 115V l
max
.
at 230V
RHD(E)250-10 1,8 A 0.9 A
RHD(E)500-10 2,2 A 1,1 A
RHD(E)800-10 5,0 A 2,5 A
RHD(E)1250-12 5,0 A 2,5 A
RHD(E)2500-25 5,0 A 2,5 A
RHD(E)4000-40 5,8 A 2,7 A
RHD(E)8000-80 5,0 A 2,5 A
RSD(E)10-5.0 2,2 A 1,1 A
RSD(E)10-10,0 3,6 A 1,8 A
RSD(E)20-5.0 3,6 A 1,8 A
RSD(E)20-7,5 4,8 A 2,4 A
RSD(E)50-3,0 5,0 A 2,5 A
RSD100-1.5 5,0 A 2,5 A
Current at electronic unit [A] (115 V
AC / 230 V AC)
RSD200-0,7 5,0 A 2,5 A
l
pos.
(115V + 230 V)
approx. 40 … 50% of
l
max.
External fuse 16 A; time-lag
