Technical data
42/68-830-EN EBN853, EBN861 (Contrac) 33
10.2 Power Electronic Unit EBN861 (Contrac)
Pos: 19.6 /Technische D aten / Datenblatt/Akt orik/Antriebe/Lei stungselektronik en/Leistungselek tronik EBN861 (Contrac )/Allgemeine Daten @ 7\mod_116884949860 9_3101.doc @ 59107
Power Electronic Unit EBN861 (Contrac)
Protection Class IP 66
Humidity
≤ 95% average; condensation not permitted
Ambient temperature -25 … 55 °C (-15 … 130 °F)
Mounting position at vertical support, cable gland at the bottom
Coating 2-layer component epoxy (RAL 9005, black)
Cable between actuator and
electronic unit
optional 5 m (16 ft), 10 m (32 ft) or 20 m (65 ft) with plug for connection to the actuator; max. cable length
between actuator and electronic unit: 100 m (328 ft)
No plug connection with RSDE… / RHDE… actuators; optional, loose cable set supplied acc. to length
requirements
Weight; approx. 40 kg (88 lbs)
Pos: 19.7 /Technische D aten / Datenblatt/Akt orik/Antriebe/Lei stungselektronik en/Leistungselek tronik EBN861 (Contrac )/Technische Date n @ 7\mod_1168849514031_31 01.doc @ 59212
Supply voltage (standard actuators) 230 V AC (190 … 260 V); 47,5 … 63 Hz; 1Ph
Supply voltage (Ex actuators) 230 V AC (190 … 253 V); 47,5 … 63 Hz; 1Ph
l
max
.
at 230V
RHD(E)2500-10 5,3 A
RHD(E)4000-10 10,0 A
RHD8000- 12 8,0 A
RHDE8000-15 8,0 A
RHD(E)16000-30 12,5 A
RSD(E)50- 10 6,4 A
RSD100-10,0 12,5 A
Current at electronic unit [A]
(230 V AC)
RSD200-5.0 13,0 A
l
pos.
(230 V)
approx. 40 … 50% of l
max.
External fuse safety fuse 35 A (Lindner) + thermal circuit breaker 16 A (ETA)
fuse and circuit breaker are part of shipment
