Additional information
Additional free publications for the µFLO
G5
flow computer are available for download
at www.abb.com/totalflow or by scanning this code:
µFLO
G5
flow computer user manual 2105614
µFLO
G5
flow computer startup guide 2105513
µFLO
G5
component replacement application guide
2105514
µFLO
G5
flow computer data sheet 2102800
µFLO
G5
(2104939 BD) wiring guide 2105507
µFLO
G5
enclosure measurements 2105508
µFLO
G5
I/O expansion board (2104395 BD) installation and wiring guide 2105506
µFLO
G5
(2104939 BD) solar panel connection 2105509
NRTL/C (Class 1, Div 2) 60 °C 2015246
NRTL/C (Class 1, Div 2) 70 °C 2104615
ATEX Cert, EX II 3G, Ex nA IIB (Zone 2) 2104152
IECEx Cert, Ex nA IIB (Zone 2) 2100750
Assumptions
For questions that are not answered in this guide or other documentation listed in the
previous section, call a local ABB representative, or call the main office number
listed on the back page of this guide.
The following apply to this guide:
— Specific instructions about collecting data, shutting in the measurement sensor,
disconnecting the high and low input lines, and manifold connections are outside
the scope of this document. At the appropriate times, guidelines prompt when
these procedures are to be performed.
— A µFLO flow computer is already installed, with either the original IMV (referred
to as the G3 IMV for clarification purposes) or the G4 IMV. The µFLO computer
is being upgraded to a µFLO
G5
.
— The host computer is running PCCU32 version 7.58 or newer.
— The optional serial communication board for the µFLO (G3) will not install on the
G5 main electronic board. An optional I/O expansion board, first available for the
µFLO
G4
, provides additional I/O and a second communication port as a separate
accessory. This board is plug and play to the new G5. Instructions for installing
and wiring the optional I/O expansion board are detailed in the startup guide
included with this kit.
