Operation Manual / 4 Product description / A100-M axial
8 Disassembly and assembly / 8.6 Removing the cartridge group
© Copyright 2019 ABB. All rights reserved. HZTL4033_DE Revision C February 2019
8.6 Removing the cartridge group
CAUTION
Safety-relevant screws
The six screws (01) are relevant for containment safety and must not be
loosened.
Fig.35: Safety-relevant screws
Page 66 / 108
