ABB ICMK14F1

Technical specifications 3 – 8 Advant Controller AC 31 / Issued: 01.99
3
40 series 50 series
07 CR 41
24 V d.c.
07 CT 41
24 V d.c.
07 CR 41
120/230 V a.c.
07 KR 51
24 V d.c.
07 KT 51
24 V d.c.
07 KR 51
120/230 V a.c.
- Weight 400 g 800 g 400 g 800 g
Power supply
- Power supply voltage:
nominal value
admissible range
24 V d.c.
19.2 to 30 V
120/230 V a.c.
97.75 to
126.5 or
195.5 to 253 V
24 V d.c.
19.2 to 30 V
120/230 V a.c.
97.75 to
126.5 V or
195.5 to 253 V
- Current consumption:
basic unit alone typical
maximum configuration typical
120 mA
400 mA
30 mA
100 mA
120 mA
400 mA
30 mA
100 mA
- Polarity reversal protection yes no yes no
- Integrated power supply 24 V d.c.
for the inputs:
voltage range
max. output current
short circuit protection
no
-
-
-
yes
19.2 to 30 V
400 mA
yes
no
-
-
-
yes
19.2 to 30 V
400 mA
yes
- Dissipation 5 W 6W 10 W 5 W 6 W 10 W
Integrated digital units
- Number of inputs 8 8 8 8 8 8
- Isolated inputs (test voltage) 1500 V a.c. 1500 V a.c. 1500 V a.c. 1500 V a.c. 1500 V a.c. 1500 V a.c.
- Input types PNP and
NPN
PNP and
NPN
PNP and
NPN
PNP and
NPN
PNP and
NPN
PNP and
NPN
- Input voltage:
nominal value
signal at 0 (IEC 1131-2)
signal at 1 (IEC 1131-2)
24 V d.c.
0 to + 5 V
+ 15 to + 30 V
24 V d.c.
0 to + 5 V
+ 15 to
+ 30 V
24 V d.c.
0 to + 5 V
+ 15 to
+ 30 V
24 V d.c.
0 to + 5 V
+ 15 to + 30 V
24 V d.c.
0 to + 5 V
+ 15 to +
30 V
24 V d.c.
0 to + 5 V
+ 15 to + 30 V
- Input current at 24 V d.c.:
inputs E62,02 to E62,07
inputs E62,00 and E62,01
7 mA
9 mA
7 mA
9 mA
7 mA
9 mA
7 mA
9 mA
7 mA
9 mA
7 mA
9 mA
- Signal delay time:
standard input
input with counter configuration
5 ms
70 µs
5 ms
70 µs
5 ms
70 µs
5 ms
70 µs
5 ms
70 µs
5 ms
70 µs
- Cable length:
unshielded (not suitable for the
high-speed counter inputs)
shielded
300 m
500 m
300 m
500 m
300 m
500 m
300 m
500 m
300 m
500 m
300 m
500 m
