ABB ICMK14F1

Advant Controller AC 31 / Issued: 01.99 3 – 9 Technical specifications
3
40 series 50 series
07 CR 41
24 V d.c.
07 CT 41
24 V d.c.
07 CR 41
120/230 V
a.c.
07 KR 51
24 V d.c.
07 KT 51
24 V d.c.
07 KR 51
120/230 V
a.c.
Integrrated outputs
- Number of outputs 6 Relays 6 Transistor 6 Relays 6 Relays 6 Transistor 6 Relays
- Isolated outputs/electronic 1500 Vrms
1 min
1500 V a.c. 1500 Vrms
1 min
1500 Vrms
1 min
1500 V a.c. 1500 Vrms
1 min
- Output current/channel at
24 V d.c.
- Output current/channel at
24 V d.c
230 V a.c.:
2 A
2 A AC-1
0.5 A AC-15
0.5 A
1 A for
A62,00 and
A62,01
-
2 A
2 A AC-1
0.5 A AC-15
2 A
2 A AC-1
0.5 A AC -15
0.5 A
1 A for
A62,00 and
A62,01
-
2 A
2 A AC-1
0.5 A AC-15
- Total load current 6 x 2 A 4 x 0.5 A
+ 2 x 1 A
6 x 2 A 6 x 2 A 4 x 0.5 A
+ 2 x 1 A
6 x 2 A
- Output leakage current -
< 200 µA
--
< 200 µA
-
- Leakage voltage - 0.5 V at
max. 500 mA
- - 0.5 V at
max. 500 mA
-
- Minimum load 10 mA under
12 V d.c.
12 V 10 mA under
12 V d.c.
10 mA under
12 V d.c.
12V 10 mA under
12 V d.c.
- Breaking capacity under 120 V a.c.
(contact rating code B300)
(UL)
2 A2 A2 A2 A
- Breaking capacity under 250 V a.c.
(contact rating code B300)
(UL)
2 A (1.5 A
acc. to
UL)
2 A (1.5 A
acc. to
UL)
2 A (1.5 A
acc. to
UL)
2 A (1.5 A
acc. to
UL)
- Number of groups 2 (2+4) 2 (2+4) 2 (2+4) 2 (2+4)
- Switching frequency:
for resistive loads
for inductive loads
for lamps
< 1 Hz
< 0.2 Hz
< 0.2 Hz
5 kHz < 1 Hz
< 0.2 Hz
< 0.2 Hz
< 1 Hz
< 0.2 Hz
< 0.2 Hz
5 kHz < 1 Hz
< 0.2 Hz
< 0.2 Hz
- Maximum number of switches:
for AC-1
for AC-15
1 million
100.000
-
-
1 million
100.000
1 million
100.000
-
-
1 million
100.000
- Short circuit and overload
protection
external thermic external external thermic external
- Surge voltage protection external yes external external yes external
- Outputs diagnosis no overload and
short circuit
no no overload and
short circuit
no
- Cable length:
unshielded
shielded
150 m
500 m
150 m
500 m
150 m
500 m
150 m
500 m
150 m
500 m
150 m
500 m
