Fläkt Woods 8265 GB 2011.10 5 Specifications are subject to alteration without notice
Installation and maintenance instruction
Fläkt Woods three phase asyncronous motor
Manufacturer: ABB
Lubricationintervalsforverticalmachinesarehalfofthe
abovevalues.
Theamountofgreasestatedinthetableshouldbedoub-
ledifanautomaticregreasingsystemisused.
Thetablevaluesarebasedonthemotorrunningatrated
outputinanambienttemperatureofabout+25°C(approx.
80°Cbearingtemperature).Thevaluesshouldbehalved
for15°Cincreaseinbearingtemperatureandmaybe
doubledfor15°Cdecreaseinambienttemperature.
Higherspeedoperation,eginfrequencyconverterapplica-
tions,orlowerspeedwithheavyloadwillrequireshorter
lubricationintervals.ConsultABBSalesOfficeinsuchcases.
Typicallyadoublingofspeedwillrequireareductionof
lubricationintervalstoapprox.40%ofvaluestabulated
above.
Suitabilityofbearingsforhighspeedoperationmustalsobe
checked.
WARNING!
 Themaximumoperatingtemperature
 ofthegreaseandbearingsmustnotbe
 exceeded.
Lubricants
Whenregreasing,useonlyspecialballbearinggrease
withthefollowingproperties:
- goodqualitygreasewithlithiumcomplexsoapand
 withmineral-orPAO-oil
- baseoilviscosity100-150cSTat40°C
- consistencyNLGIgrade2or3
- temperaturerange-30°C-+120°C,continuously.
Greasewiththecorrectpropertiesisavailablefromall
themajorlubricantmanufacturers.
Thefollowing(orsimilar)highperformancegreasecan
beused
• EssoUnirex N2orN3
• Shell AlbidaEMS2
• SKF  LGHQ3
• Mobil MobilithSHC100
• Klüber KluberplexBEM41-132
• BP  EnergreaseLC2
 NOTE!
 Alwaysusehighspeedgreaseforhighspeed
 machinensandsomeothermodels,e.g.M2_355
 and4002-polemachines,wherethespeedfactoris
 higherthan400000(calculatedasDmxnwhere
 Dm=averagebearingdiameter,mm;n=rotational
 speed,rpm).Thefollowing,orsimilar,typesof
 greasecanbeused:
• Kluber AsonicGHY72
• Kluber AsonicHQ72-102
• Shell AlbidaEMS2
• Esso  LT2
• Mobil MobilithSHC100
Thefollowingnormaltypeofgreasecanbeusedifthe
regreasingintervalishalved(thesetypesofgreaseshould
notbeusedwhenbearingtemperatureisabove100°C).
• Esso  Beacon2or3
• Shell AlvaniaRL2orRL3
• SKF  LGMT2or3
• Mobil Mobilux2
• Kluber Centoplex2
• BP  EnergreaseLS2
Ifthemakeofgreaseischangedandcompatibilityis
uncertain,consultABBSalesOffice.
Highlyloadedand/orslowlyrotatingbearingsrequire
EPgrease.
Iftheambienttemperatureisbelow-25°Corabove
+55°C,orbearingtemperatureisabove110°C,consult
ABBSalesOfficeregardingsuitablegrease.
Frame
size
Amount
of grease
g/bearing
3600
r/min
3000
r/min
1800
r/min
1500
r/min
1000
r/min
500-900
r/min
Ball bearings
Lubrication intervals in duty hours
112 10 10000 13000 18000 21000 25000 28000
132 15 9000 11000 17000 19000 23000 26500
160 25 7000 9500 14000 17000 21000 24000
180 30 6000 8000 13500 16000 20000 23000
200 40 4000 6000 11000 13000 17000 21000
225 50 3000 5000 10000 12500 16500 20000
250 60 2500 4000 9000 11500 15000 18000
280 70 2000 3500 8000 10500 14000 17000
315 90 2000 3500 6500 8500 12500 16000
355 120 1200 2000 4200 6000 10000 13000
400 120 1200 2000 4200 6000 10000 13000
Roller bearings
Lubrication intervals in duty hours
160 25 3500 4500 7000 8500 10500 12000
180 30 3000 4000 7000 8000 10000 11500
200 40 2000 3000 5500 6500 8500 10500
225 50 1500 2500 5000 6000 8000 10000
250 60 1300 2000 4500 5700 7500 9000
280 70 1000 1700 4000 5300 7000 8500
315 90 1000 1700 3300 4300 6000 8000
355 120 400 1000 2000 3000 5000 6500
400 120 400 1000 2000 3000 5000 6500
WARNING!
 Greasecancauseskinirritationandeye
 inflammation.Followallsafetyprecau-
 tionsspecifiedbythemanufacturer.
