13-1 Typical wiring diagram for M102-M 24VDC DOL PART 1/2
—
13-1 Typical wiring diagram for M102-M 24VDC DOL PART 2/2
Wiring Tip:
Using an interface relay between contac-
tor control output relay and contactor coil
will improve the performance and service
life of M10x relay. For a contactor load A75
and above, it is recommended to use an in-
terposing relay.
Typical Wiring Diagram M102-M 24VDC
The terminal layout of M102-M 24VDC
product type is shown as an example in
Fig 12. The terminal blocks may have dif-
ferent definitions and available terminals
depending on the selected product type.
The details are explained in terminal des-
ignations above.
03 . INSTALLATION AND WIRING 21
