1.7 Stop – Enable Switch Test
This stage verifies correct function of the Stop – Enable switch.
No
Description
Check
57.
Start the PCS100 AVC-40 Verify the PCS100 AVC-40 UL enters RUN mode, and no
faults exist.
58.
Turn the Stop - Enable switch to Stop to bypass the PCS100 AVC-40. Verify the
PCS100 AVC-40 enters BYPASS mode, and no faults exist. INHIBIT will be shown on
the GDM.
59.
Return the Stop - Enable switch to Enable. Verify the PCS100 AVC-40 remains in
BYPASS mode. INHIBIT will be removed from the display.
1.8 Initial Run – No Load
This stage verifies correct function of the inverter.
No
Description
Check
60.
Start the PCS100 AVC-40. Verify the PCS100 AVC-40 enters RUN mode, and no faults
exist.
61.
Stop the PCS100 AVC-40. Verify the PCS100 AVC-40 returns to the BYPASS mode and
no faults exist.
62.
Access the menu and change 600 V Set Manual to 105% of the nominal supply voltage
and start the PCS100 AVC-40. The PCS100 AVC-40 will correct the output voltage to
105% of nominal supply voltage.
Verify the GDM Output Voltage measurements show 105% of nominal supply voltage
on the status page, and that no faults exist.
63.
Stop the PCS100 AVC-40. Verify the PCS100 AVC-40 returns to BYPASS and set 600 V
Set Manual back to 100% of the nominal supply voltage or set to needed level.
