AC500-eCo - 6 - Hardware Introduction
Overview of the S500 I/O Module
AI523 AX521 AX522 AO523 AI561 AO561 AX561 AI562 AI563
Number of Channels per Module
analoge Inputs
16x 4x 8x - 4x - 4x - -
analoge Outputs
- 4x 8x 16x - 2x 2x - -
Inputs, single configurable
-2.5V…+2.5V
- - - - x - x - -
-5V…+5V
- - - - x - x - -
0…5V
- - - - x - x - -
0…10V
x x x - x - x - -
0…20mA
- - - - x - x - -
4…20mA
x x x - x - x - -
Outputs, single configurable
-10V…+10V
- x x x - x x - -
0…20mA
- - - - - x x - -
4…20mA
- x x x - x x - -
Inputs
RTD
x x x - - - - 2x -
Thermo couple
- - - - - - - - 4x
S500-eCo
