1SFC132081M0201 | Installation and commissioning manual | Functions 81
7.4 Full voltage start
When using the full voltage start, the Softstarter increases
the motor speed as fast as possible. The motor voltage
ramps up to full voltage in ½ seconds.
INFORMATION
Full voltage start ignores the Current limit.
Configuration of the Full voltage start with these
parameters:
Parameter Description Setting range Default value
02.01 Start mode Set to Full voltage start. Voltage ramp,
Torque ramp,
Full voltage start
Voltage ramp
7.5 Direct stop
When using the Direct stop the output voltage to the
motor is 0.
Configuration of the Direct stop with these
parameters:
Parameter Description Setting range Default value
02.02 Stop mode Set to No ramp. No ramp,
Voltage stop
ramp, Torque
stop ramp,
Dynamic brake
Voltage ramp
7
