- 58 -
000867AG
5 - Installation
• Lift the inverter up to the bracket
using the handles
14
, or ano-
ther appropriate lifting device.
The inverter is pre-equipped with
lower support
24
which allow it
to be temporarily put vertically
on the oor to make it easier the
lifting.
Risk of injury due to
the heavy weight of
the equipment.
• Insert the heads of six anchor
point
03
present on the bracket
into the slots on the rear of the
inverter.
03
