ABB REB650 - Settings for each Step

U
ref
I
dir
IEC09000636_2_vsd
1
2
2
3
4
IEC09000636 V2 EN-US
Figure 38: Directional function characteristic
1. RCA = Relay characteristic angle
2. ROA = Relay operating angle
3. Reverse
4. Forward
7.1.3.1 Settings for each step
M12982-19 v10
x means step 1, 2, 3 and 4.
DirModex: The directional mode of step x. Possible settings are Off/Non-
directional/Forward/Reverse.
Characteristx: Selection of time characteristic for step x. Definite time delay and
different types of inverse time characteristics are available according to Table
12.
Section 7 1MRK 505 388-UEN B
Current protection
94 Busbar protection REB650 2.2 IEC
Application manual
