3.7 BINARY OUTPUTS
AND BINARY OUTPUT
COMMANDS
Binary Outputs Group
Number: 10
Binary Output Events
Group Number: 11
Binary Output
Commands Group
Number: 12
Binary Output Command
Events Group Number:
13
Capabilities
(leave tick-boxes blank if
this data type is not
supported)
Current Value
If configurable, list
methods
○ Variation 1 –
command status
without time
Not Supported
○ Variation 2 –
command status with
time
○ Based on point Index
(add column to table in
part 5)
3.7.8 Event reporting mode: When responding with event data and more than one event has occurred for
a data point, an Outstation may include all events or only the most recent event
○ Only most recent
● All events
3.7.9 Command Event reporting mode: When responding with event data and more than one event has
occurred for a data point, an Outstation may include all events or only the most recent event
○ Only most recent Not Supported
○ All events
3.7.10 Maximum Time between Select and Operate:
○ Not Applicable 30 seconds PST or LHMI
(tSelectTimeout)
○ Fixed at _____
seconds
● Configurable, range 1
to 60 seconds
○ Configurable,
selectable
from___,___,___
seconds
○ Configurable, other,
describe:
○ Variable, explain:
○ Based on point Index
(add column to table in
part 5)
3.7.11 Binary Outputs Event Buffer Organization: When event buffers are allocated per object group (see
part 1.7.6), indicate the number of events that can be buffered for Binary Outputs. If event buffers are not
allocated per object group then set “Fixed at 0”.
Table continues on next page
1MRK 511 419-UUS A Section 3
DNP3 protocol implementation
650 series 2.2 ANSI 55
Point list manual
